BoolDrive BD1D50 Evaluation Board

BoolDrive BD1D50 Evaluation Board is a basic reference design and an evaluation board for the BoolDrive BD1D50 motor control module. When combined with BoolDrive BD1D50, it makes a complete PMSM motor controller suitable for bench testing and evaluation of the Telega motor control technology.

It can come with an integrated CANFace CF2 "Babel-Babel", an all-in-one debugger for robotics & drone development.

All external signals of BoolDrive are accessible via the pin headers. BoolDrive BD1D50 Evaluation Board also provides dedicated connectors for 2 Cyphal/CAN interfaces, a Dronecode debug port, and one Aux connector for GPIO and RCPWM. The motor phase wires and the DC link input are connected via M3 screw terminals.

• Supply voltage range: 13--51 V.
• Max continuous current/peak phase current amplitude: 10/20 A.
• Designed strictly for indoor use.

Send an email to sales@zubax.com for access to the documentation.
